For the absolute version Serial Synchronous Interface SSI output provides effective synchronisation in a closed-loop control system. A clock pulse train from a controller is used to shift out sensor data: one bit of position data is transmitted to the controller per clock pulse received by the sensor. Incremental versions provide two channels in quadrature with complements and an index. Resolutuions up to 10,000 cpt are available.
Features
- Designed for use in Class I, Div.1 & Zone 1 hazardous areas
- Low profile package saves space
- Excellent resistance to shock and vibration
- 30mm standard through shaft, PEEK reduction hub available
- High protection level of IP66
- High performance in temperatures from –40°C to +100°C
- Resolutions up to 10,000 PPR, incremental or 16 BITS absolute
- Terminal box with Conduit Termination
- Encapsulated electronics
- TTL and HTL electronics
- Reinforced electrical output available on some incremental and absolute models
- Wiring fault tolerant with terminal box connection
- Long cable drive capability
