IPF electronic Incremental encoder VD580828
rotary encoder, Ø58mm 65long, Full shaft 6mm, 2000 pulses, 4.75-30V DC, -25-85°C, Push-pull, Connector M23 12pin, IP54, Aluminum
Additional information
About IPF Electronic
IPF Electronic GmbH is a German manufacturer and specializes in connection technology, data technology and sensor technology. In the beginning the main target for IPH Electronic was to create innovative products that would revolutionize the industrial world. IPF Electronic distributor is the one, which provides its high quality products worldwide. Step by step the company has grown and nowadays it is represented on the international market, for example IPF Electronic usa.
GET A PRICE
To receive a proposal, please send your application to info@shop-encoder.com and specify the required positions and company details.
Specification
Electrical features Betriebsspannung (DC): 4.75 - 30V
Increments per revolution: 2.000
No-load current: 30mA
Switching frequency: 150.000Hz
Type of switching output: Push-pull
Physical measurement principle: Optic
Reverse polarity protection: yes
Rated switching current: 20mA
Shaft length: 10
Number of pins: 12
Type of electrical connection: Connector M23
Short-circuit protection: yes
Encoder signal outputs: A+B+0
Mechanical features Ambient temperature: -25 - 85°C
Flange material: Aluminum
Cable infeed: Radial
Encoder size: 58
Vibration resistance, frequency: 2.000Hz
Start-up torque: 0,01
Shock resistance, acceleration: 200g
Max. rotation speed: 10.000UpM
Sensor diameter: 58mm
Axial load capacity of shaft: 20N
Vibration resistance, acceleration: 10g
Degree of protection (IP): IP54
Flange: Clamping flange
Type of encoder shaft: Full shaft
Moment of inertia: 14,5gcm²
Shock resistance, pulse time: 6ms
Radial load capacity of the shaft: 40N
Sensor length: 65mm
Shaft diameter: 6mm
Housing material: Aluminum
Other features Air humidity(MIN): 0 - 95%
Ausführung: Incremental encoder
Increments per revolution: 2.000
No-load current: 30mA
Switching frequency: 150.000Hz
Type of switching output: Push-pull
Physical measurement principle: Optic
Reverse polarity protection: yes
Rated switching current: 20mA
Shaft length: 10
Number of pins: 12
Type of electrical connection: Connector M23
Short-circuit protection: yes
Encoder signal outputs: A+B+0
Mechanical features Ambient temperature: -25 - 85°C
Flange material: Aluminum
Cable infeed: Radial
Encoder size: 58
Vibration resistance, frequency: 2.000Hz
Start-up torque: 0,01
Shock resistance, acceleration: 200g
Max. rotation speed: 10.000UpM
Sensor diameter: 58mm
Axial load capacity of shaft: 20N
Vibration resistance, acceleration: 10g
Degree of protection (IP): IP54
Flange: Clamping flange
Type of encoder shaft: Full shaft
Moment of inertia: 14,5gcm²
Shock resistance, pulse time: 6ms
Radial load capacity of the shaft: 40N
Sensor length: 65mm
Shaft diameter: 6mm
Housing material: Aluminum
Other features Air humidity(MIN): 0 - 95%
Ausführung: Incremental encoder
