The RH 200 metric wheels are designed for specific industrial applications where is required to measure a linear movement (i.e. continuous sheet cutting machines of wood, textiles, glass, etc.). Precise reading and high-stress resistance are the main features of these encoders. The body is entirely designed of aluminium and mounted using an oscillating arm pivoted on the shaft. It comes with an integrated self-lubricating compact box to assure a long operation period without any maintenance. The weight of the metric wheel keeps a stable contact with the material, allowing an accurate measurement of both length and speed. The wheel surface can be in crossed-knurl aluminium, special anti-oil or anti-sliding rubber. RH200
Eltra RH 200 B Encoder
Description
Additional information
| Brand |
|---|
About Eltra
Eltra, like many other great businesses, began as an entrepreneurial ambition in a garage. But what began as a recreational hobby quickly evolved into a viable business venture, and Eltra, situated in the current Sarego facility, was founded in 1985.
GET A PRICE
To receive a proposal, please send your application to info@shop-encoder.com and specify the required positions and company details.
Specification
| Shaft diameter (max) | 8 mm |
| Resolution (max) | 1.024 ppr |
| Output frequency (max) | 105 kHz |
| Operating temperature (°C) | -20° ... +70° |
| Enclosure rating | IP 54 |
| Stroke length | 200 mm |
